75 Shore A Black FKM Viton Rubber Gasket Sheet
75 Shore A black FKM Viton rubber gasket sheet that has been designed to satisfy your current service purposes in the Chemical, Oil as well as Gas
Send Inquiry
Product Description
FKM Viton Rubber Gasket Sheet - V705
Find a huge selection of 75 Shore A Black FKM Viton Rubber Gasket Sheet from China at Kaxite. 75 Shore A black FKM Viton rubber gasket sheet that has been designed to satisfy your current service purposes in the Chemical, Oil as well as Gas, and other industrial trading markets where 100% Fluoroelastomer (FKM) rubber is essential. FKM Viton rubber sheet has high effectiveness against heat with a temp range of -20 to 230 ℃ and also it also offers a very good flames resistance as well as is usually self extinguishing75 Shore A black FKM Viton rubber gasket sheet features a utility-grade satin end as well as is certainly proofed against acids, aliphatic and also aromatic hydrocarbons, fuels and ozone. A great content to use in heater treaters and environments that call-out the need for a 100% Fluroelastomer (FKM) material. In addition to our FKM viton rubber gasket sheet is usually a affordable 100% Fluroelastomer that won't burst your financial budget
Benefits and features of FKM Viton Rubber Gasket Sheet
75 Shore A black FKM Viton rubber gasket sheet is composed of 100% Fluoroelastomer (FKM‚ Type A). It is black in color with a utility-grade satin finish. FKM Viton rubber gasket sheet is resistant to acids, aliphatic and aromatic hydrocarbons, fuels and ozone.Applications of Viton FKM Rubber Sheets
75 Shore A black FKM Viton rubber gasket sheet now utilised regularly inside the vehicle, equipment, substance variety, and also fluid energy sectors simply because of its natural amount of resistance to both energy and gas. As well as energy and engine essential oil opposition, Viton rubber gaskets and other elements comes with a highly effective excellent reputation as being a substantial-undefinedefficiency elastomer which could functionality in sizzling hot and very corrosive configurations. These sorts of capabilities make Viton an ordinary choice for elements that require to achieve success in stressful conditions.Physical Properties
| Testing Items | Test Method | Test Results | Unit |
| Color | - | Black | - |
| Hardness | ASTM D2240 | 75±5 | Shore A |
| Density | ASTM D297 | 1.95 | g/cm3 |
| Tensil Strength | ASTM D412 | ≥8.5 | Mpa |
| Elongation at break | ASTM D412 | ≥180 | % |
| Compression Set (24hrs @ 70°C) | ASTM D395B |
30 |
% |
| Temperature Range | - | -20 - +220 | °C |
